Flatpak build error

Dec 9, 2020
C

As @llothar recently wrote: “Flatpak itself seem to not have it’s own forum…”, so I’m here.

I’ve successfully built a Flatpak for “myapp” without one of its dependencies. When I try again with that included it fails with

...configure: creating ./config.status
config.status: creating Makefile
config.status: creating glu.pc
config.status: executing depfiles commands
config.status: executing libtool commands
  CC       src/libutil/error.lo
  CC       src/libutil/glue.lo
  CC       src/libutil/mipmap.lo
src/libutil/error.c:60:10: error: ‘NULL’ undeclared here (not in a function)
   60 |    { ~0, NULL } /* end of list indicator */
      |          ^~~~
src/libutil/error.c:34:1: note: ‘NULL’ is defined in header ‘<stddef.h>’; did you forget to ‘#include <stddef.h>’?
   33 | #include <GL/glu.h>
  +++ |+#include <stddef.h>
   34 |
make: *** [Makefile:1119: src/libutil/error.lo] Error 1
make: *** Waiting for unfinished jobs....
Error: module glu: Child process exited with code 2

It used to work originally, but now I have some time to attempt to finish it, it no longer works.
I don’t know anything about the included application or how to compile it - someone very helpfully wrote that part of the .yml file for me. I can include more of the yml file if that would help.

C

This part didn’t link to an existing download, until I added the ‘.git’ could that be it? I don’t know why it has ‘Commit:’ where the other parts have what I would expect - ‘sha256:’ .

H
Replying to #2

sha256 is a checksum for a file. commit is a commit in git.

But if you want to build exiv2, I recommend doing like other packages do, like https://github.com/flathub/com.rawtherapee.RawTherapee/blob/master/com.rawtherapee.RawTherapee.yaml#L160

C
Replying to #3

From there I copied and pasted

  • name: exiv2
    buildsystem: cmake-ninja
    builddir: true
    config-opts:
    • -DCMAKE_BUILD_TYPE=RelWithDebInfo
    • -DEXIV2_BUILD_DOC:BOOL=OFF
    • -DEXIV2_BUILD_SAMPLES:BOOL=OFF
    • -DEXIV2_BUILD_EXIV2_COMMAND:BOOL=OFF
      sources:
    • type: archive
      url: http://www.exiv2.org/builds/exiv2-0.27.3-Source.tar.gz
      sha256: a79f5613812aa21755d578a297874fb59a85101e793edc64ec2c6bd994e3e778
    • type: patch
      path: exiv2-build-arm.patch

This fails with

Failed to download sources: module exiv2: Can’t find file at exiv2-build-arm.patch

C
Replying to #3

I was reluctant to mess with a manifest (specification file) which was written by an expert and I didn’t understand. However, since it no longer works I haven’t got a lot to lose! I have removed all the sections except the one for the particular function I want. That seemed to work better, but later errored complaining it was missing something - which was in another section. Replacing that too has resulted in the building taking a very long time - which is a good thing as it means progress. I’m waiting for it to finish - one way or another.

Edit: It keeps failing complaining that bits are missing, so I keep replacing them, looks like they may all be necessary after all.

H
Replying to #5

which app is that?

You need to get the patch from the same repository and put it next to the manifest.

H
Replying to #6

Are you trying to flatpak Hugin?

(I have it locally here, but the build segfault on 20.08 and work on 19.08)

C
Replying to #7

That sounds useful, myapp uses an OS call to run align-image-stack on some files. I don’t need any other Hugin function. I think align-image-stack is a part of hugin-tools.

If you were able to pick out the bits that are needed I’d be interested to see it.

H
Replying to #8

You can have a look at the PR (draft)

C
Replying to #9

I’ll compare that with what I’ve got.

C
Replying to #9

I will use your version of exiv and I have found the patch for exiv here https://github.com/flathub/com.rawtherapee.RawTherapee/blob/master/exiv2-build-arm.patch but have no idea to include it so have missed it out. Since it mentions “arm”, I’m wondering whether that is something to do with ARM processors and I might not need it.

I had a look at sourceforge, then decided to retry with what I’ve got first. I removed the sections except align-image-stack and replaced them as the build complained about them being missing. They were all necessary. It all seems alright (for about 1/2hr) until it gets to here:

[62/304] Building CXX object src/hugin…inbase.dir/panodata/SrcPanoImage.cpp.o
FAILED: src/hugin_base/CMakeFiles/huginbase.dir/panodata/SrcPanoImage.cpp.o
/usr/bin/c++ -DGLEW_STATIC -Dhuginbase_EXPORTS -Isrc -I…/src/hugin_base -I…/src/celeste -Isrc/celeste -I…/src -I/app/include/OpenEXR -I/app/include -I…/src/foreign -march=x86-64 -mtune=generic -O2 -g -pipe -Wp,-D_FORTIFY_SOURCE=2 -Wp,-D_GLIBCXX_ASSERTIONS -fexceptions -fstack-protector-strong -grecord-gcc-switches -fasynchronous-unwind-tables -fstack-clash-protection -fcf-protection -O2 -g -DNDEBUG -fPIC -fopenmp -pthread -std=gnu++11 -MD -MT src/hugin_base/CMakeFiles/huginbase.dir/panodata/SrcPanoImage.cpp.o -MF src/hugin_base/CMakeFiles/huginbase.dir/panodata/SrcPanoImage.cpp.o.d -o src/hugin_base/CMakeFiles/huginbase.dir/panodata/SrcPanoImage.cpp.o -c …/src/hugin_base/panodata/SrcPanoImage.cpp
…/src/hugin_base/panodata/SrcPanoImage.cpp: In member function ‘bool HuginBase::SrcPanoImage::readEXIF()’:
…/src/hugin_base/panodata/SrcPanoImage.cpp:358:30: error: expected unqualified-id before ‘&’ token
catch (const Exiv2::Error& e)
^
…/src/hugin_base/panodata/SrcPanoImage.cpp:358:30: error: expected ‘)’ before ‘&’ token
catch (const Exiv2::Error& e)
~ ^
)
…/src/hugin_base/panodata/SrcPanoImage.cpp:358:30: error: expected ‘{’ before ‘&’ token
…/src/hugin_base/panodata/SrcPanoImage.cpp:358:32: error: ‘e’ was not declared in this scope
catch (const Exiv2::Error& e)
^
[63/304] Building CXX object src/hugin…dir/panodata/ImageVariableGroup.cpp.o

Hopefully if we can align-image-stack working it will be a step towards you getting your Hugin Flatpak working.

H
Replying to #11

the build from the pull request above should actually work. Just that it uses the 19.08 runtime.

C
Replying to #12

I don’t really understand that. Are you saying that the exiv section should be okay? Is it related to this section?

runtime: org.gnome.Platform
runtime-version: “3.30”
sdk: org.gnome.Sdk

H
Replying to #13

This section might be the whole problem. the 3.30 SDK is old. Try 3.36, or 3.38. But for Hugin I just use the org.freedesktop.Platform//19.08 platform / SDK

C
Replying to #14

Mixup! I was supposed to be using 3.38, but I went back to the original manifest to get rid of my mods adn forgot to edit out ‘3.30’. Correcting it to 3.38 brings back the original error. I’ll install org.freedesktop.Platform//19.08 platform / SDK and try that.

H
Replying to #15

the matching GNOME sdk is 3.36 if you prefer that.

(not having the content of your manifest makes it all a guess work)

C
Replying to #16

I couldn’t find a way to attach it and hadn’t included it inline because I thought it was too big, but here it is.

> app-id: com.github.myapp.myapp
> runtime: org.gnome.Platform
> runtime-version: "3.38"
> sdk: org.gnome.Sdk
> command: myapp
> rename-desktop-file: myapp.desktop
> rename-icon: myapp_logo
> copy-icon: true
> finish-args:
>   - --share=ipc
>   - --socket=x11
>   - --socket=wayland
>   - --filesystem=xdg-run/dconf
>   - --filesystem=~/.config/dconf:ro
>   - --talk-name=ca.desrt.dconf
>   - --env=DCONF_USER_CONFIG_DIR=.config/dconf
>   - --filesystem=host:rw
> modules:
>   - name: python3-pillow
>     buildsystem: simple
>     build-commands:
>       - pip3 install --no-index --find-links="file://${PWD}" --prefix=${FLATPAK_DEST} Pillow Pillow-PIL
>     sources:
>       - type: file
>         url: https://files.pythonhosted.org/packages/3c/7e/443be24431324bd34d22dd9d11cc845d995bcd3b500676bcf23142756975/Pillow-5.4.1.tar.gz
>         sha256: 5233664eadfa342c639b9b9977190d64ad7aca4edc51a966394d7e08e7f38a9f
>       - type: file
>         url: https://files.pythonhosted.org/packages/5d/e1/d298934cd78984a5e8d616945349ed66a74b9df0337fb1941ce76b8a2b7b/Pillow-PIL-0.1dev.tar.gz
>         sha256: d80ee30805f10bf898df9ce7495f46e88990e8f90b5c2b917722d87526252b2c
>
>   # Hugin deps
>   - shared-modules/glew/glew.json
>   - shared-modules/glu/glu-9.0.0.json
>
>   - name: wxWidgets
>     rm-configure: true
>     cleanup:
>       - /bin
>       - /share/bakefile
>     config-opts:
>       - --with-opengl
>       - --with-libjpeg
>       - --with-libtiff
>       - --with-libpng
>       - --with-zlib
>       - --disable-sdltest
>       - --enable-unicode
>       - --enable-display
>       - --enable-propgrid
>       - --disable-webkit
>       - --disable-webview
>       - --disable-webviewwebkit
>       - --with-expat=builtin
>       - --with-libiconv=/usr
>     build-options:
>       cxxflags: "-std=c++0x"
>     sources:
>       - type: archive
>         url: https://github.com/wxWidgets/wxWidgets/releases/download/v3.0.4/wxWidgets-3.0.4.tar.bz2
>         sha256: 96157f988d261b7368e5340afa1a0cad943768f35929c22841f62c25b17bf7f0
>     cleanup:
>       - /bin
>       - /lib
>       - /doc
>       - /share
>
>   - name: libpano13
>     buildsystem: cmake # cmake-ninja doesn't work OK with libpano13 and __FILE__ macro in its sources
>     builddir: true
>     sources:
>       - type: archive
>         url: https://downloads.sourceforge.net/project/panotools/libpano13/libpano13-2.9.19/libpano13-2.9.19.tar.gz
>         sha256: 037357383978341dea8f572a5d2a0876c5ab0a83dffda431bd393357e91d95a8
>     cleanup:
>       - /bin
>       - /share
>
>   - name: ilmbase
>     config-opts:
>       - --disable-static
>     sources:
>       - type: archive
>         url: https://download.savannah.nongnu.org/releases/openexr/ilmbase-2.2.1.tar.gz
>         sha256: cac206e63be68136ef556c2b555df659f45098c159ce24804e9d5e9e0286609e
>
>   - name: openexr
>     config-opts:
>       - --disable-static
>     sources:
>       - type: archive
>         url: https://download.savannah.nongnu.org/releases/openexr/openexr-2.2.1.tar.gz
>         sha256: 8f9a5af6131583404261931d9a5c83de0a425cb4b8b25ddab2b169fbf113aecd
>     cleanup:
>       - /bin
>       - /share/doc
>
>   - name: vigra
>     buildsystem: cmake-ninja
>     config-opts:
>        - -DWITH_OPENEXR=ON
>     sources:
>       - type: archive
>         url: https://github.com/ukoethe/vigra/archive/Version-1-11-1.tar.gz
>         sha256: b2718250d28baf1932fcbe8e30f7e4d146e751ad0e726e375a72a0cdb4e3250e
>     cleanup:
>       - /bin
>       - /doc
>       - /lib/vigra/
>       - /share
>
>   - name: exiv2
>     buildsystem: cmake-ninja
>     builddir: true
>     config-opts:
>       - -DCMAKE_BUILD_TYPE=RelWithDebInfo
>       - -DEXIV2_BUILD_DOC:BOOL=OFF
>       - -DEXIV2_BUILD_SAMPLES:BOOL=OFF
>       - -DEXIV2_BUILD_EXIV2_COMMAND:BOOL=OFF
>     sources:
>       - type: archive
>         url: http://www.exiv2.org/builds/exiv2-0.27.3-Source.tar.gz
>         sha256: a79f5613812aa21755d578a297874fb59a85101e793edc64ec2c6bd994e3e778
>
>   - name: boost
>     buildsystem: simple
>     build-commands:
>       - "./bootstrap.sh --prefix=/app --with-libraries=atomic,chrono,date_time,filesystem,iostreams,program_options,system,thread"
>       - "./b2 -j $FLATPAK_BUILDER_N_JOBS install"
>     sources:
>       - type: archive
>         url: https://dl.bintray.com/boostorg/release/1.68.0/source/boost_1_68_0.tar.bz2
>         sha256: 7f6130bc3cf65f56a618888ce9d5ea704fa10b462be126ad053e80e553d6d8b7
>
>   - name: align_image_stack
>     buildsystem: cmake-ninja
>     builddir: true
>     sources:
>       - type: archive
>         url: https://downloads.sourceforge.net/project/hugin/hugin/hugin-2018.0/hugin-2018.0.0.tar.bz2
>         sha256: d3af0d066ac50e3bb243a175a64ecda136d87178419457e8822e11bcf0e565cb
>     cleanup:
>       - /bin/autooptimiser
>       - /bin/calibrate_lens_gui
>       - /bin/celeste_standalone
>       - /bin/checkpto
>       - /bin/cpclean
>       - /bin/cpfind
>       - /bin/deghosting_mask
>       - /bin/fulla
>       - /bin/geocpset
>       - /bin/hugin*
>       - /bin/icpfind
>       - /bin/linefind
>       - /bin/nona
>       - /bin/pano*
>       - /bin/PT*
>       - /bin/pto_*
>       - /bin/tca_correct
>       - /bin/verdandi
>       - /bin/vig_optimize
>       - /lib/libceleste*
>       - /lib/libhuginbaswwx*
>       - /lib/libicpfindlib*
>       - /lib/liblocalfeatures*
>       - /share
>
>   - name: myapp
>     buildsystem: meson
>     sources:
>       - type: git
>         url: https://github.com/myapp/myapp
C
Replying to #16
configure: creating ./config.status
config.status: creating Makefile
config.status: creating glu.pc
config.status: executing depfiles commands
config.status: executing libtool commands
  CC       src/libutil/error.lo
  CC       src/libutil/glue.lo
  CC       src/libutil/mipmap.lo
src/libutil/error.c:60:10: error: ‘NULL’ undeclared here (not in a function)
   60 |    { ~0, NULL } /* end of list indicator */
      |          ^~~~
src/libutil/error.c:34:1: note: ‘NULL’ is defined in header ‘<stddef.h>’; did you forget to ‘#include <stddef.h>’?
   33 | #include <GL/glu.h>
  +++ |+#include <stddef.h>
   34 |
make: *** [Makefile:1119: src/libutil/error.lo] Error 1
make: *** Waiting for unfinished jobs....
Error: module glu: Child process exited with code 2

Using 36 I still get the same old error.

I thought I’d better include these from the shared-modules directory.
glu-9.0.0.json

{
  "name": "glu",
  "config-opts": ["--disable-static"],
  "sources": [
    {
      "type": "archive",
      "url": "https://mesa.freedesktop.org/archive/glu/glu-9.0.0.tar.bz2",
      "sha256": "1f7ad0d379a722fcbd303aa5650c6d7d5544fde83196b42a73d1193568a4df12"
    }
  ],
  "cleanup": [ "/include", "/lib/*.a", "/lib/*.la", "/lib/pkgconfig" ]
}

glew.json

{
“name”: “glew”,
“no-autogen”: true,
“make-args”: [
“GLEW_PREFIX=/app”,
“GLEW_DEST=/app”,
“LIBDIR=/app/lib”
],
“make-install-args”: [
“GLEW_PREFIX=/app”,
“GLEW_DEST=/app”,
“LIBDIR=/app/lib”
],
“sources”: [
{
“type”: “archive”,
“url”: “Download glew-2.1.0.tgz (The OpenGL Extension Wrangler Library)”,
“sha256”: “04de91e7e6763039bc11940095cd9c7f880baba82196a7765f727ac05a993c95”
}
],
“cleanup”: [
“/include”,
“/lib/pkgconfig”,
“/lib/*.a”
]
}

C
Replying to #18

Strangely three of my posts have been hidden because they are “spam” or “advertisements”, I suspect the system is a trifle over-sensitive.

H
Replying to #19

Try updating the shared-modules and then you need to use the renamed json. The manifest for glu has changed, and I suspect that the source of your troubles.
